145P
Hammond Manufacturing
Hammond Manufacturing
TRANSFORMER AUDIO 20K/1KCT IMPED
$24.02
Available to order
Reference Price (USD)
1+
$20.55000
10+
$18.13500
25+
$17.53040
50+
$15.71700
100+
$15.11250
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Boost your audio projects with Hammond Manufacturing 145P Audio Transformers, known for their robust construction and exceptional sound quality. These transformers are ideal for a wide range of applications, from PA systems to musical instruments, providing reliable and distortion-free performance. Count on Hammond Manufacturing for excellence in every component. Contact us now to discuss your requirements.
Specifications
- Product Status: Active
- Turns Ratio - Primary:Secondary: -
- Impedance - Primary (Ohms): 20k
- Impedance - Secondary (Ohms): 1kCT
- DC Resistance (DCR) - Primary: 1.18kOhm
- DC Resistance (DCR) - Secondary: 50Ohm
- Transformer Type: Economical Open Type
- Frequency Range: 150Hz ~ 15kHz
- Frequency Response: ±1dB
- Voltage - Isolation: -
- Insertion Loss: -
- Return Loss: -
- Power Level: 135mW
- Operating Temperature: -
- Approval Agency: -
- Mounting Type: Chassis Mount
- Size / Dimension: 1.630" L x 0.880" W (41.40mm x 22.35mm)
- Height - Seated (Max): 0.810" (20.57mm)
- Termination Style: Wire Leads
