5145-0-00-15-00-00-03-0
Mill-Max Manufacturing Corp.
Mill-Max Manufacturing Corp.
PRESS-FIT PCB PIN FOR A NON-PLAT
$0.46
Available to order
Reference Price (USD)
1+
$0.46000
500+
$0.4554
1000+
$0.4508
1500+
$0.4462
2000+
$0.4416
2500+
$0.437
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Choose 5145-0-00-15-00-00-03-0 Mill-Max Manufacturing Corp. Terminals - PC Pin, Single Post Connectors for dependable and high-performance electrical connections. With attributes such as high-temperature tolerance, low contact resistance, and compact size, these connectors are perfect for space-constrained applications. They are widely used in automotive, aerospace, and renewable energy sectors. Submit your inquiry today, and let us help you find the right connectors for your project.
Specifications
- Product Status: Active
- Terminal Type: PC Pin
- Terminal Style: Single End
- Pin Size - Above Flange: 0.018" (0.46mm) Dia
- Pin Size - Below Flange: 0.023" (0.58mm) Dia
- Length - Above Flange: 0.165" (4.18mm)
- Length - Below Flange: 0.045" (1.14mm)
- Length - Overall: 0.230" (5.84mm)
- Flange Diameter: 0.045" (1.14mm)
- Mounting Hole Diameter: 0.026" (0.66mm)
- Mounting Type: Through Hole
- Termination: Press-Fit, Knurled
- Insulation: Non-Insulated
- Board Thickness: -
- Contact Material: Brass Alloy
- Contact Finish: Gold
- Contact Finish Thickness: 10.0µin (0.25µm)
