800-10-019-61-001000

Mill-Max Manufacturing Corp.
800-10-019-61-001000 Preview
Mill-Max Manufacturing Corp.
CONN HEADER VERT 19POS 2.54MM
800-10-019-61-001000 Datasheet
$4.98
Available to order
Reference Price (USD)
1+
$4.30000
10+
$4.12700
25+
$3.78320
50+
$3.61120
100+
$3.43920
250+
$3.00932
500+
$2.92336
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram

Specifications

  • Product Status: Active
  • Connector Type: Header
  • Contact Type: Male Pin
  • Pitch - Mating: 0.100" (2.54mm)
  • Number of Positions: 19
  • Number of Rows: 1
  • Row Spacing - Mating: -
  • Number of Positions Loaded: All
  • Style: Board to Board
  • Shrouding: Unshrouded
  • Mounting Type: Through Hole
  • Termination: Press-Fit, Solder
  • Fastening Type: Push-Pull
  • Contact Length - Mating: 0.191" (4.85mm)
  • Contact Length - Post: 0.104" (2.64mm)
  • Overall Contact Length: 0.405" (10.29mm)
  • Insulation Height: 0.110" (2.79mm)
  • Contact Shape: Circular
  • Contact Finish - Mating: Gold
  • Contact Finish Thickness - Mating: 10.0µin (0.25µm)
  • Contact Finish - Post: Gold
  • Contact Material: Brass Alloy
  • Insulation Material: Polycyclohexylenedimethylene Terephthalate (PCT)
  • Features: -
  • Operating Temperature: -
  • Ingress Protection: -
  • Material Flammability Rating: -
  • Insulation Color: Black
  • Current Rating (Amps): -
  • Voltage Rating: -
