800-V3-010-40-001101

Preci-Dip

Manufacturer

Preci-Dip

Description:

CONN HEADER SMD R/A 10POS 2.54MM

Datasheet:

800-V3-010-40-001101 Datasheet

$1.27

Available to order

Reference Price (USD)

360+

$1.34139

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

The 800-V3-010-40-001101 Preci-Dip Rectangular Connectors - Headers, Male Pins offer unmatched reliability for your electronic assembly needs. With features like corrosion resistance, high-temperature tolerance, and easy mating, these connectors are suited for aerospace, medical devices, and more. Trust Preci-Dip for top-tier connectivity solutions. Interested? Get in touch today for pricing and availability!

Specifications

Product Status: Active
Connector Type: Header
Contact Type: Male Pin
Pitch - Mating: 0.100" (2.54mm)
Number of Positions: 10
Number of Rows: 1
Row Spacing - Mating: -
Number of Positions Loaded: All
Style: Board to Board
Shrouding: Unshrouded
Mounting Type: Surface Mount, Right Angle
Termination: Solder
Fastening Type: Push-Pull
Contact Length - Mating: 0.191" (4.85mm)
Contact Length - Post: -
Overall Contact Length: -
Insulation Height: 0.100" (2.54mm)
Contact Shape: Circular
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 29.5µin (0.75µm)
Contact Finish - Post: Tin
Contact Material: Brass
Insulation Material: Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Features: -
Operating Temperature: -55°C ~ 125°C
Ingress Protection: -
Material Flammability Rating: UL94 V-0
Insulation Color: Black
Current Rating (Amps): 3A
Voltage Rating: 150VDC
