APT25GR120SD15
Microchip Technology
Microchip Technology
IGBT 1200V 75A 521W D3PAK
$8.02
Available to order
Reference Price (USD)
1+
$10.15000
10+
$9.13300
25+
$8.32120
100+
$7.50930
250+
$6.90044
500+
$6.29158
1,000+
$5.47977
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Choose APT25GR120SD15 Single IGBTs by Microchip Technology for superior power handling in demanding environments. From railway systems to industrial drives, these transistors excel with features like avalanche ruggedness and integrated diodes. Their modular design simplifies installation and maintenance. Microchip Technology's reputation for quality makes APT25GR120SD15 a smart investment. Email us now for datasheets and volume discounts!
Specifications
- Product Status: Active
- IGBT Type: NPT
- Voltage - Collector Emitter Breakdown (Max): 1200 V
- Current - Collector (Ic) (Max): 75 A
- Current - Collector Pulsed (Icm): 100 A
- Vce(on) (Max) @ Vge, Ic: 3.2V @ 15V, 25A
- Power - Max: 521 W
- Switching Energy: 742µJ (on), 427µJ (off)
- Input Type: Standard
- Gate Charge: 203 nC
- Td (on/off) @ 25°C: 16ns/122ns
- Test Condition: 600V, 25A, 4.3Ohm, 15V
- Reverse Recovery Time (trr): -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
- Supplier Device Package: D3Pak
