APT54GA60B
Microchip Technology
Microchip Technology
IGBT 600V 96A 416W TO-247
$6.39
Available to order
Reference Price (USD)
83+
$6.63060
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Choose APT54GA60B Single IGBTs by Microchip Technology for superior power handling in demanding environments. From railway systems to industrial drives, these transistors excel with features like avalanche ruggedness and integrated diodes. Their modular design simplifies installation and maintenance. Microchip Technology's reputation for quality makes APT54GA60B a smart investment. Email us now for datasheets and volume discounts!
Specifications
- Product Status: Active
- IGBT Type: PT
- Voltage - Collector Emitter Breakdown (Max): 600 V
- Current - Collector (Ic) (Max): 96 A
- Current - Collector Pulsed (Icm): 161 A
- Vce(on) (Max) @ Vge, Ic: 2.5V @ 15V, 32A
- Power - Max: 416 W
- Switching Energy: 534µJ (on), 466µJ (off)
- Input Type: Standard
- Gate Charge: 158 nC
- Td (on/off) @ 25°C: 17ns/112ns
- Test Condition: 400V, 32A, 4.7Ohm, 15V
- Reverse Recovery Time (trr): -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247 [B]
