B82432C1474J000
EPCOS - TDK Electronics
EPCOS - TDK Electronics
FIXED IND 470UH 75MA 17.5OHM SMD
$0.49
Available to order
Reference Price (USD)
5,000+
$0.38745
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Upgrade your projects with B82432C1474J000 Fixed Inductors by EPCOS - TDK Electronics, engineered for optimal efficiency and durability. With features like high Q factor, minimal core losses, and compact designs, these inductors are perfect for telecommunications, automotive systems, and energy management. B82432C1474J000 ensures superior performance in demanding environments. Ready to enhance your designs? Request a sample or inquire about pricing now!
Specifications
- Product Status: Active
- Type: Drum Core, Wirewound
- Material - Core: Ferrite
- Inductance: 470 µH
- Tolerance: ±5%
- Current Rating (Amps): 75 mA
- Current - Saturation (Isat): -
- Shielding: Unshielded
- DC Resistance (DCR): 17.5Ohm Max
- Q @ Freq: 30 @ 796kHz
- Frequency - Self Resonant: 4MHz
- Ratings: AEC-Q200
- Operating Temperature: -55°C ~ 125°C
- Inductance Frequency - Test: 100 kHz
- Features: -
- Mounting Type: Surface Mount
- Package / Case: 2-SMD, J-Lead
- Supplier Device Package: 1812 (4532 Metric)
- Size / Dimension: 0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max): 0.134" (3.40mm)
