BAW56Q-7-F
Diodes Incorporated
Diodes Incorporated
DIODE SW DL 75V 150MA SOT23
$0.04
Available to order
Reference Price (USD)
3,000+
$0.03300
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The BAW56Q-7-F by Diodes Incorporated is a top choice in the Discrete Semiconductor Products sector, particularly for Diodes - Rectifiers - Arrays. These diodes are designed to meet the highest standards of performance and reliability, offering features like low forward drop and high reverse voltage. Ideal for power supplies, inverters, and more, the BAW56Q-7-F ensures efficient energy conversion. Diodes Incorporated prides itself on delivering products that exceed expectations. Reach out to us today to discuss your project requirements!
Specifications
- Product Status: Active
- Diode Configuration: 1 Pair Common Anode
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 75 V
- Current - Average Rectified (Io) (per Diode): 150mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 4 ns
- Current - Reverse Leakage @ Vr: 2.5 µA @ 75 V
- Operating Temperature - Junction: -65°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3
