CA3524EX

Harris Corporation

Manufacturer

Harris Corporation

Description:

REGULATING PULSE WIDTH MODULATOR

Datasheet:

CA3524EX Datasheet

$0.71

Available to order

Reference Price (USD)

$0.71000

500+

$0.7029

1000+

$0.6958

1500+

$0.6887

2000+

$0.6816

2500+

$0.6745

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

Upgrade your power management systems with the CA3524EX DC DC Switching Controller by Harris Corporation. This cutting-edge PMIC voltage regulator provides precise voltage control, high efficiency, and robust thermal performance, perfect for demanding applications in telecommunications, computing, and renewable energy systems. Harris Corporation's CA3524EX is engineered to optimize power delivery while reducing overall system costs. Interested in integrating this solution into your project? Submit an inquiry now for personalized assistance and pricing details.

Specifications

Product Status: Active
Output Type: Transistor Driver
Function: Step-Up, Step-Down
Output Configuration: Positive
Topology: Flyback, Push-Pull
Number of Outputs: 2
Output Phases: 1
Voltage - Supply (Vcc/Vdd): 8V ~ 40V
Frequency - Switching: Up to 300kHz
Duty Cycle (Max): 45%
Synchronous Rectifier: No
Clock Sync: No
Serial Interfaces: -
Control Features: Current limit, Dead Time Control, Enable, Frequency Control, Ramp
Operating Temperature: 0°C ~ 70°C
Mounting Type: Through Hole
Package / Case: 16-DIP (0.300", 7.62mm)
Supplier Device Package: 16-PDIP
