EFD12/6/3.5-3F36-S
Ferroxcube
Ferroxcube
FERRITE CORE 2PC SET
$2.13
Available to order
Reference Price (USD)
1+
$1.62000
10+
$1.39300
25+
$1.05880
50+
$1.00320
100+
$0.89170
250+
$0.83600
500+
$0.78026
1,000+
$0.71617
5,000+
$0.69666
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Upgrade your electronic designs with premium Ferroxcube EFD12/6/3.5-3F36-S Ferrite Cores, designed for superior magnetic performance and thermal stability. Perfect for applications in switch-mode power supplies, RF transformers, and noise filters. These cores offer low core loss and high permeability, making them a reliable choice for demanding environments. Whether for industrial, medical, or consumer electronics, our Ferrite Cores deliver unmatched quality. Request a sample or inquire about bulk pricing now!
Specifications
- Product Status: Active
- Core Type: EFD
- Supplier Device Package: EFD 12 x 6 x 3.5
- Material: 3F36
- Diameter: -
- Inductance Factor (Al): -
- Tolerance: ±25%
- Gap: Ungapped
- Effective Permeability (µe): 1130
- Initial Permeability (µi): -
- Core Factor (ΣI/A) mm-1: 2.5
- Effective Length (le) mm: 28.5
- Effective Area (Ae) mm²: 11.4
- Minimum Core Cross Section (Amin) mm²: 10.7
- Effective Magnetic Volume (Ve) mm³: 325
- Finish: Uncoated
- Height: 0.244" (6.20mm)
- Length: 0.492" (12.50mm)
- Width: 0.138" (3.50mm)
