FF1800R12IE5BPSA1
Infineon Technologies
Infineon Technologies
IGBT MOD 1200V 1800A 20MW
$1,325.45
Available to order
Reference Price (USD)
2+
$991.01500
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The FF1800R12IE5BPSA1 from Infineon Technologies sets the standard in IGBT Modules with its compact design and high power density. Ideal for servo drives and plasma cutting, it combines fast switching with low conduction losses. Partner with Infineon Technologies for top-tier semiconductor solutions. Get in touch for details!
Specifications
- Product Status: Active
- IGBT Type: Trench Field Stop
- Configuration: 2 Independent
- Voltage - Collector Emitter Breakdown (Max): 1200 V
- Current - Collector (Ic) (Max): 1800 A
- Power - Max: 20 mW
- Vce(on) (Max) @ Vge, Ic: 2.15V @ 15V, 1800A
- Current - Collector Cutoff (Max): 5 mA
- Input Capacitance (Cies) @ Vce: 98.5 nF @ 25 V
- Input: Standard
- NTC Thermistor: Yes
- Operating Temperature: -40°C ~ 175°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: Module
- Supplier Device Package: Module
