FGAF40S65AQ
onsemi
onsemi
650V 40A FS4 SA IGBT
$4.02
Available to order
Reference Price (USD)
1+
$3.56000
30+
$2.49033
120+
$2.13442
510+
$1.71941
1,020+
$1.57712
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The FGAF40S65AQ Single IGBT by onsemi sets the standard for power semiconductor excellence. Designed for applications like electric vehicles and industrial machinery, it offers high current density and minimal thermal resistance. Key benefits include easy integration, superior durability, and compliance with international certifications. Partner with onsemi for cutting-edge solutions tailored to your needs. Contact us now to discuss specifications and delivery options!
Specifications
- Product Status: Active
- IGBT Type: Trench Field Stop
- Voltage - Collector Emitter Breakdown (Max): 650 V
- Current - Collector (Ic) (Max): 80 A
- Current - Collector Pulsed (Icm): 160 A
- Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 40A
- Power - Max: 94 W
- Switching Energy: 132µJ (on), 62µJ (off)
- Input Type: Standard
- Gate Charge: 75 nC
- Td (on/off) @ 25°C: 17.8ns/81.6ns
- Test Condition: 400V, 10A, 6Ohm, 15V
- Reverse Recovery Time (trr): 274 ns
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-3P-3 Full Pack
- Supplier Device Package: TO-3PF-3
