HCPL-0631-000E
Broadcom Limited
Broadcom Limited
OPTOISO 3.75KV 2CH OPEN COLL 8SO
$5.28
Available to order
Reference Price (USD)
1+
$4.55000
10+
$3.78800
25+
$3.18160
100+
$2.72700
300+
$2.42400
500+
$2.19676
1,000+
$2.01495
2,500+
$1.93162
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The Broadcom Limited HCPL-0631-000E Optoisolators - Logic Output are engineered for precision and reliability in demanding environments. Key features include high-speed data transmission, excellent EMI resistance, and robust packaging. Ideal for use in aerospace, defense, and telecommunications, these isolators deliver unmatched performance. Contact us to learn more or place an order!
Specifications
- Product Status: Active
- Number of Channels: 2
- Inputs - Side 1/Side 2: 2/0
- Voltage - Isolation: 3750Vrms
- Common Mode Transient Immunity (Min): 10kV/µs
- Input Type: DC
- Output Type: Open Collector, Schottky Clamped
- Current - Output / Channel: 50 mA
- Data Rate: 10MBd
- Propagation Delay tpLH / tpHL (Max): 100ns, 100ns
- Rise / Fall Time (Typ): 24ns, 10ns
- Voltage - Forward (Vf) (Typ): 1.5V
- Current - DC Forward (If) (Max): 15mA
- Voltage - Supply: 4.5V ~ 5.5V
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SO Tall
