HCPL-7720-560E
Broadcom Limited
Broadcom Limited
OPTOISO 3.75KV PUSH PULL 8DIP GW
$3.68
Available to order
Reference Price (USD)
2,000+
$2.60100
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover high-quality Broadcom Limited HCPL-7720-560E Optoisolators - Logic Output, designed for reliable signal isolation in various electronic applications. These optoisolators feature excellent noise immunity, high-speed performance, and robust construction, making them ideal for industrial automation, telecommunications, and medical equipment. Ensure safe and efficient signal transmission with our premium isolators. Contact us today for a quote or more information!
Specifications
- Product Status: Active
- Number of Channels: 1
- Inputs - Side 1/Side 2: 1/0
- Voltage - Isolation: 3750Vrms
- Common Mode Transient Immunity (Min): 10kV/µs
- Input Type: Logic
- Output Type: Push-Pull, Totem Pole
- Current - Output / Channel: 10 mA
- Data Rate: 25MBd
- Propagation Delay tpLH / tpHL (Max): 40ns, 40ns
- Rise / Fall Time (Typ): 9ns, 8ns
- Voltage - Forward (Vf) (Typ): -
- Current - DC Forward (If) (Max): -
- Voltage - Supply: 4.5V ~ 5.5V
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Package / Case: 8-SMD, Gull Wing
- Supplier Device Package: 8-DIP Gull Wing
Related Products
onsemi
HCPL2631SDM
Broadcom Limited
HCPL-2200-300E
Broadcom Limited
5962-8957101PC
onsemi
H11L3SR2M
Broadcom Limited
5962-0824202HXA
Broadcom Limited
HCPL-263L-320E
onsemi
H11L3SM
Broadcom Limited
HCNW2601#300
Vishay Semiconductor Opto Division
