MSC015SMA070B
Microchip Technology
Microchip Technology
SICFET N-CH 700V 131A TO247-3
$32.62
Available to order
Reference Price (USD)
1+
$32.62000
500+
$32.2938
1000+
$31.9676
1500+
$31.6414
2000+
$31.3152
2500+
$30.989
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover MSC015SMA070B, a versatile Transistors - FETs, MOSFETs - Single solution from Microchip Technology, a trusted name in Discrete Semiconductor Products. This MOSFET combines high power density with low on-resistance, perfect for compact and energy-efficient designs. Applications include solar inverters, electric vehicles, and wearable technology. Interested in this innovative component? Send us your inquiry now for more information!
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: SiCFET (Silicon Carbide)
- Drain to Source Voltage (Vdss): 700 V
- Current - Continuous Drain (Id) @ 25°C: 131A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 20V
- Rds On (Max) @ Id, Vgs: 19mOhm @ 40A, 20V
- Vgs(th) (Max) @ Id: 2.4V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs: 215 nC @ 20 V
- Vgs (Max): +25V, -10V
- Input Capacitance (Ciss) (Max) @ Vds: 4500 pF @ 700 V
- FET Feature: -
- Power Dissipation (Max): 400W (Tc)
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Supplier Device Package: TO-247-3
- Package / Case: TO-247-3
