NCD57090DDWR2G
onsemi
onsemi
ISOLATED HIGH CURRENT GATE DRIVE
$3.09
Available to order
Reference Price (USD)
1+
$3.09000
500+
$3.0591
1000+
$3.0282
1500+
$2.9973
2000+
$2.9664
2500+
$2.9355
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Elevate your designs with onsemi NCD57090DDWR2G Gate Driver Isolators, offering top-tier isolation and signal integrity. These isolators are equipped with high noise rejection, fast switching speeds, and compliance with international safety standards. Suitable for traction inverters, test equipment, and more, they ensure peak performance. Start your order process contact us today!
Specifications
- Product Status: Active
- Technology: Capacitive Coupling
- Number of Channels: 1
- Voltage - Isolation: 5000Vrms
- Common Mode Transient Immunity (Min): 100kV/µs (Max)
- Propagation Delay tpLH / tpHL (Max): 90ns, 90ns
- Pulse Width Distortion (Max): 25ns
- Rise / Fall Time (Typ): 13ns, 13ns
- Current - Output High, Low: 6.5A, 6.5A
- Current - Peak Output: 6.5A
- Voltage - Forward (Vf) (Typ): -
- Current - DC Forward (If) (Max): -
- Voltage - Output Supply: 0V ~ 32V
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 8-SOIC
- Approval Agency: VDE
