P0396NL
Pulse Electronics Power
Pulse Electronics Power
INDUCT ARRAY 2 COIL 3.5UH SMD
$3.18
Available to order
Reference Price (USD)
1+
$3.18000
500+
$3.1482
1000+
$3.1164
1500+
$3.0846
2000+
$3.0528
2500+
$3.021
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The P0396NL Pulse Electronics Power Inductors, Coils, and Chokes are designed to excel in Arrays and Signal Transformers applications. Offering high efficiency, compact size, and robust performance, they are ideal for portable electronics and power management systems. Don t miss out get a quote today and see why leading engineers trust our products!
Specifications
- Product Status: Active
- Number of Coils: 2
- Inductance - Connected In Parallel: 3.5 µH
- Inductance - Connected In Series: 14 µH
- Tolerance: ±20%
- Current Rating - Parallel: 11.2 A
- Current Rating - Series: 5.6 A
- Current Saturation - Parallel: -
- Current Saturation - Series: -
- DC Resistance (DCR) - Parallel: 6.54mOhm
- DC Resistance (DCR) - Series: 26.2mOhm
- Shielding: Unshielded
- Ratings: -
- Operating Temperature: -40°C ~ 130°C
- Mounting Type: Surface Mount
- Package / Case: Nonstandard
- Size / Dimension: 0.715" L x 0.590" W (18.16mm x 14.99mm)
- Height: 0.310" (7.87mm)
