PF0553.223NLT
Pulse Electronics Power
Pulse Electronics Power
INDUCT ARRAY 2 COIL 23UH SMD
$2.54
Available to order
Reference Price (USD)
1+
$2.54000
500+
$2.5146
1000+
$2.4892
1500+
$2.4638
2000+
$2.4384
2500+
$2.413
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Achieve peak performance with PF0553.223NLT Pulse Electronics Power Inductors, Coils, and Chokes, tailored for Arrays and Signal Transformers. These components feature advanced materials and precise engineering, ensuring reliability in automotive, industrial, and consumer applications. For more details or to discuss your specific needs, reach out to our team now we re here to help!
Specifications
- Product Status: Active
- Number of Coils: 2
- Inductance - Connected In Parallel: 23 µH
- Inductance - Connected In Series: 92 µH
- Tolerance: ±20%
- Current Rating - Parallel: 3.9 A
- Current Rating - Series: 2 A
- Current Saturation - Parallel: 7.6 A
- Current Saturation - Series: 3.8 A
- DC Resistance (DCR) - Parallel: 39mOhm Max
- DC Resistance (DCR) - Series: 160mOhm Max
- Shielding: Shielded
- Ratings: -
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: Nonstandard
- Size / Dimension: 0.492" L x 0.492" W (12.50mm x 12.50mm)
- Height: 0.315" (8.00mm)
