PS9305L-AX
CEL
CEL
OPTOISO 5KV GATE DRIVER 8SDIP GW
$5.51
Available to order
Reference Price (USD)
1+
$5.40000
10+
$4.50000
25+
$3.78000
100+
$3.24000
250+
$2.88000
500+
$2.61000
1,000+
$2.39400
2,500+
$2.29500
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Experience next-level isolation with CEL PS9305L-AX Gate Driver Isolators, designed for precision and reliability. Featuring fast response times, high dielectric strength, and ESD protection, these isolators excel in motor control, power supplies, and telecom infrastructure. Partner with us for tailored solutions send your inquiry now!
Specifications
- Product Status: Active
- Technology: Optical Coupling
- Number of Channels: 1
- Voltage - Isolation: 5000Vrms
- Common Mode Transient Immunity (Min): 25kV/µs
- Propagation Delay tpLH / tpHL (Max): 250ns, 250ns
- Pulse Width Distortion (Max): 100ns
- Rise / Fall Time (Typ): 50ns, 50ns
- Current - Output High, Low: 2A, 2A
- Current - Peak Output: 2.5A
- Voltage - Forward (Vf) (Typ): 1.56V
- Current - DC Forward (If) (Max): 25 mA
- Voltage - Output Supply: 15V ~ 30V
- Operating Temperature: -40°C ~ 110°C
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.268", 6.81mm Width)
- Supplier Device Package: 8-SDIP Gull Wing
- Approval Agency: CSA, SEMKO, UL
