S2305
SMC Diode Solutions
SMC Diode Solutions
TVS DIODE 5VWM 10.8VC SOT23
$0.36
Available to order
Reference Price (USD)
1+
$0.36000
500+
$0.3564
1000+
$0.3528
1500+
$0.3492
2000+
$0.3456
2500+
$0.342
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Protect your circuits effortlessly with SMC Diode Solutions's S2305 TVS Diodes, designed for high-speed data lines and power applications. These diodes feature excellent clamping performance, low dynamic resistance, and high thermal stability. Suitable for telecom infrastructure, automotive electronics, and more, they ensure reliable operation under stress. Get started with SMC Diode Solutions send us your inquiry!
Specifications
- Product Status: Active
- Type: Zener
- Unidirectional Channels: -
- Bidirectional Channels: 1
- Voltage - Reverse Standoff (Typ): 5V (Max)
- Voltage - Breakdown (Min): 6V
- Voltage - Clamping (Max) @ Ipp: 10.8V
- Current - Peak Pulse (10/1000µs): 1A
- Power - Peak Pulse: 300W
- Power Line Protection: No
- Applications: USB
- Capacitance @ Frequency: 400pF @ 1MHz
- Operating Temperature: -55°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3
