SN74ALS20ADBR
Texas Instruments
Texas Instruments
IC GATE NAND 2CH 4-INP 14SSOP
$0.30
Available to order
Reference Price (USD)
1+
$0.30000
500+
$0.297
1000+
$0.294
1500+
$0.291
2000+
$0.288
2500+
$0.285
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Experience next-gen performance with Texas Instruments's SN74ALS20ADBR Logic Gates and Inverters, tailored for complex digital systems. Highlights include bidirectional operation, fail-safe outputs, and Pb-free construction, serving data centers, AI hardware, and sensor networks. Texas Instruments prioritizes customer satisfaction with rigorous testing protocols. For datasheets or partnership opportunities, reach out now!
Specifications
- Product Status: Obsolete
- Logic Type: NAND Gate
- Number of Circuits: 2
- Number of Inputs: 4
- Features: -
- Voltage - Supply: 4.5V ~ 5.5V
- Current - Quiescent (Max): -
- Current - Output High, Low: 400µA, 8mA
- Logic Level - Low: 0.8V
- Logic Level - High: 2V
- Max Propagation Delay @ V, Max CL: 12.5ns @ 5V, 50pF
- Operating Temperature: 0°C ~ 70°C
- Mounting Type: Surface Mount
- Supplier Device Package: 14-SSOP
- Package / Case: 14-SSOP (0.209", 5.30mm Width)
