WCL2520-220-R
Eaton - Electronics Division
Eaton - Electronics Division
FIXED IND 22UH 105MA 3.9 OHM SMD
$0.26
Available to order
Reference Price (USD)
1+
$0.26000
500+
$0.2574
1000+
$0.2548
1500+
$0.2522
2000+
$0.2496
2500+
$0.247
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The WCL2520-220-R Fixed Inductors from Eaton - Electronics Division offer unmatched precision for your electronic applications. Featuring robust construction, wide temperature range tolerance, and excellent EMI suppression, these inductors are ideal for medical devices, aerospace, and IoT solutions. WCL2520-220-R guarantees reliability and longevity. Need technical specifications or volume discounts? Reach out to our team for more details!
Specifications
- Product Status: Active
- Type: Drum Core, Wirewound
- Material - Core: Ceramic
- Inductance: 22 µH
- Tolerance: ±5%
- Current Rating (Amps): 105 mA
- Current - Saturation (Isat): -
- Shielding: Unshielded
- DC Resistance (DCR): 3.9Ohm Max
- Q @ Freq: 10 @ 2.52MHz
- Frequency - Self Resonant: 18MHz
- Ratings: -
- Operating Temperature: -40°C ~ 85°C
- Inductance Frequency - Test: 2.52 MHz
- Features: -
- Mounting Type: Surface Mount
- Package / Case: 1008 (2520 Metric)
- Supplier Device Package: 1008
- Size / Dimension: 0.115" L x 0.110" W (2.92mm x 2.79mm)
- Height - Seated (Max): 0.083" (2.10mm)
