106G
Hammond Manufacturing
Hammond Manufacturing
TRANSFORMER AUDIO 4000/600CT
$30.70
Available to order
Reference Price (USD)
1+
$25.52000
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Boost your audio projects with Hammond Manufacturing 106G Audio Transformers, known for their robust construction and exceptional sound quality. These transformers are ideal for a wide range of applications, from PA systems to musical instruments, providing reliable and distortion-free performance. Count on Hammond Manufacturing for excellence in every component. Contact us now to discuss your requirements.
Specifications
- Product Status: Active
- Turns Ratio - Primary:Secondary: -
- Impedance - Primary (Ohms): 4k
- Impedance - Secondary (Ohms): 600CT
- DC Resistance (DCR) - Primary: 340Ohm
- DC Resistance (DCR) - Secondary: 24Ohm
- Transformer Type: Miniature Epoxy Potted
- Frequency Range: 215Hz
- Frequency Response: -1dB
- Voltage - Isolation: 200V
- Insertion Loss: 1dB
- Return Loss: -
- Power Level: 150mW
- Operating Temperature: -
- Approval Agency: -
- Mounting Type: Through Hole
- Size / Dimension: 1.080" L x 0.880" W (27.43mm x 22.35mm)
- Height - Seated (Max): 0.950" (24.13mm)
- Termination Style: PC Pin
