APT50GN120L2DQ2G
Microchip Technology
Microchip Technology
IGBT 1200V 134A 543W TO264
$17.94
Available to order
Reference Price (USD)
1+
$19.04000
10+
$17.30700
25+
$16.00920
100+
$14.71130
250+
$13.41320
500+
$12.54784
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The APT50GN120L2DQ2G Single IGBT by Microchip Technology sets the standard for power semiconductor excellence. Designed for applications like electric vehicles and industrial machinery, it offers high current density and minimal thermal resistance. Key benefits include easy integration, superior durability, and compliance with international certifications. Partner with Microchip Technology for cutting-edge solutions tailored to your needs. Contact us now to discuss specifications and delivery options!
Specifications
- Product Status: Active
- IGBT Type: NPT, Trench Field Stop
- Voltage - Collector Emitter Breakdown (Max): 1200 V
- Current - Collector (Ic) (Max): 134 A
- Current - Collector Pulsed (Icm): 150 A
- Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 50A
- Power - Max: 543 W
- Switching Energy: 4495µJ (off)
- Input Type: Standard
- Gate Charge: 315 nC
- Td (on/off) @ 25°C: 28ns/320ns
- Test Condition: 800V, 50A, 2.2Ohm, 15V
- Reverse Recovery Time (trr): -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-264-3, TO-264AA
- Supplier Device Package: -
