FGAF40N60SMD
onsemi
onsemi
IGBT FIELD STOP 600V 80A TO3PF
$5.26
Available to order
Reference Price (USD)
1+
$4.84000
10+
$4.34800
360+
$3.37994
720+
$3.03282
1,080+
$2.55780
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Upgrade your power electronics with FGAF40N60SMD Single IGBTs by onsemi, engineered for precision and durability. Perfect for inverters, welding equipment, and automotive applications, these transistors provide fast switching speeds and excellent thermal stability. Key features include high voltage tolerance, low power loss, and compact design. Trust onsemi for top-quality components that meet global standards. Request a quote now to learn more about how FGAF40N60SMD can enhance your projects.
Specifications
- Product Status: Active
- IGBT Type: Field Stop
- Voltage - Collector Emitter Breakdown (Max): 600 V
- Current - Collector (Ic) (Max): 80 A
- Current - Collector Pulsed (Icm): 120 A
- Vce(on) (Max) @ Vge, Ic: 1.9V @ 15V, 40A
- Power - Max: 115 W
- Switching Energy: 870µJ (on), 260µJ (off)
- Input Type: Standard
- Gate Charge: 119 nC
- Td (on/off) @ 25°C: 12ns/92ns
- Test Condition: 400V, 40A, 6Ohm, 15V
- Reverse Recovery Time (trr): 36 ns
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-3P-3 Full Pack
- Supplier Device Package: TO-3PF
