IKQ120N60TXKSA1
Infineon Technologies
Infineon Technologies
IGBT 600V 160A TO247-3-46
$13.45
Available to order
Reference Price (USD)
1+
$13.74000
10+
$12.71400
240+
$10.90721
720+
$9.82307
1,200+
$9.12040
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Upgrade your power electronics with IKQ120N60TXKSA1 Single IGBTs by Infineon Technologies, engineered for precision and durability. Perfect for inverters, welding equipment, and automotive applications, these transistors provide fast switching speeds and excellent thermal stability. Key features include high voltage tolerance, low power loss, and compact design. Trust Infineon Technologies for top-quality components that meet global standards. Request a quote now to learn more about how IKQ120N60TXKSA1 can enhance your projects.
Specifications
- Product Status: Active
- IGBT Type: Trench Field Stop
- Voltage - Collector Emitter Breakdown (Max): 600 V
- Current - Collector (Ic) (Max): 160 A
- Current - Collector Pulsed (Icm): 480 A
- Vce(on) (Max) @ Vge, Ic: 2V @ 15V, 120A
- Power - Max: 833 W
- Switching Energy: 6.2mJ (on), 5.9mJ (off)
- Input Type: Standard
- Gate Charge: 703 nC
- Td (on/off) @ 25°C: 50ns/565ns
- Test Condition: 400V, 120A, 3Ohm, 15V
- Reverse Recovery Time (trr): 241 ns
- Operating Temperature: -40°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: PG-TO247-3-46
