P0396NLT
Pulse Electronics Power
Pulse Electronics Power
INDUCT ARRAY 2 COIL 3.5UH SMD
$1.59
Available to order
Reference Price (USD)
1+
$1.59075
500+
$1.5748425
1000+
$1.558935
1500+
$1.5430275
2000+
$1.52712
2500+
$1.5112125
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Enhance your circuit designs with P0396NLT Pulse Electronics Power Inductors, Coils, and Chokes, specifically designed for Arrays and Signal Transformers. These components offer high reliability, low DCR, and superior frequency response, making them suitable for telecommunications and computing applications. For more information or to place an order, reach out to our sales team now!
Specifications
- Product Status: Active
- Number of Coils: 2
- Inductance - Connected In Parallel: 3.5 µH
- Inductance - Connected In Series: 14 µH
- Tolerance: ±20%
- Current Rating - Parallel: 11.2 A
- Current Rating - Series: 5.6 A
- Current Saturation - Parallel: -
- Current Saturation - Series: -
- DC Resistance (DCR) - Parallel: 6.54mOhm
- DC Resistance (DCR) - Series: 26.2mOhm
- Shielding: Unshielded
- Ratings: -
- Operating Temperature: -40°C ~ 130°C
- Mounting Type: Surface Mount
- Package / Case: Nonstandard
- Size / Dimension: 0.715" L x 0.590" W (18.16mm x 14.99mm)
- Height: 0.310" (7.87mm)
