PMN23UN,135
NXP USA Inc.
NXP USA Inc.
MOSFET N-CH 20V 6.3A 6TSOP
$0.12
Available to order
Reference Price (USD)
1+
$0.12000
500+
$0.1188
1000+
$0.1176
1500+
$0.1164
2000+
$0.1152
2500+
$0.114
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
PMN23UN,135 by NXP USA Inc. is a standout in the Discrete Semiconductor Products market, specifically for Transistors - FETs, MOSFETs - Single applications. Engineered for precision, this MOSFET offers exceptional gate control, low leakage current, and high power density. Ideal for use in audio amplifiers, DC-DC converters, and battery management systems, PMN23UN,135 ensures top-tier performance. Don t miss out on this versatile component request a sample or quote now!
Specifications
- Product Status: Obsolete
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 20 V
- Current - Continuous Drain (Id) @ 25°C: 6.3A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 1.8V, 4.5V
- Rds On (Max) @ Id, Vgs: 28mOhm @ 2A, 4.5V
- Vgs(th) (Max) @ Id: 700mV @ 1mA (Typ)
- Gate Charge (Qg) (Max) @ Vgs: 10.6 nC @ 4.5 V
- Vgs (Max): ±8V
- Input Capacitance (Ciss) (Max) @ Vds: 740 pF @ 10 V
- FET Feature: -
- Power Dissipation (Max): 1.75W (Tc)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: SC-74
- Package / Case: SC-74, SOT-457
Related Products
Alpha & Omega Semiconductor Inc.
AON6276
onsemi
HUF75345G3
Vishay Siliconix
SIR5708DP-T1-RE3
IXYS
IXTA1N120P-TRL
Vishay Siliconix
SIHP12N60E-BE3
STMicroelectronics
SCTW90N65G2V
Vishay Siliconix
SIHB24N65EFT1-GE3
Micro Commercial Co
MCQ05N15-TP
Nexperia USA Inc.
PSMNR60-25YLHX
