QT2601
QT Brightek (QTB)
QT Brightek (QTB)
8 PIN 10 MBITS HIGH SPEED LOGIC
$4.59
Available to order
Reference Price (USD)
1+
$4.50000
10+
$3.75000
40+
$3.15000
120+
$2.70000
280+
$2.40000
520+
$2.17500
1,000+
$1.99500
2,520+
$1.91250
5,000+
$1.86000
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The QT Brightek (QTB) QT2601 Optoisolators - Logic Output provide exceptional electrical isolation for your critical circuits. Featuring fast response times, high isolation voltage, and compact design, these optoisolators are suited for applications in renewable energy, automotive electronics, and consumer devices. Enhance your project's safety and efficiency. Get in touch for pricing details!
Specifications
- Product Status: Active
- Number of Channels: 1
- Inputs - Side 1/Side 2: 1/0
- Voltage - Isolation: 5000Vrms
- Common Mode Transient Immunity (Min): 5kV/µs
- Input Type: DC
- Output Type: Open Collector
- Current - Output / Channel: 50 mA
- Data Rate: 10Mbps
- Propagation Delay tpLH / tpHL (Max): 75ns, 75ns
- Rise / Fall Time (Typ): 37ns, 10ns
- Voltage - Forward (Vf) (Typ): 1.4V
- Current - DC Forward (If) (Max): 50mA
- Voltage - Supply: 7V
- Operating Temperature: -55°C ~ 85°C
- Mounting Type: Through Hole
- Package / Case: 8-DIP (0.300", 7.62mm)
- Supplier Device Package: 8-DIP
