SQD40020EL_GE3
Vishay Siliconix
Vishay Siliconix
MOSFET N-CH 40V 100A TO252AA
$1.72
Available to order
Reference Price (USD)
1+
$1.72000
500+
$1.7028
1000+
$1.6856
1500+
$1.6684
2000+
$1.6512
2500+
$1.634
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Upgrade your electronic designs with SQD40020EL_GE3 by Vishay Siliconix, a top-tier choice in Discrete Semiconductor Products. Specifically crafted for Transistors - FETs, MOSFETs - Single applications, this product offers superior power handling and energy efficiency. Key features include high voltage tolerance, minimal power loss, and robust durability, making it perfect for switching and amplification tasks. Whether for industrial machinery, renewable energy systems, or portable devices, SQD40020EL_GE3 ensures reliable operation. Ready to integrate this component into your project? Submit an inquiry now for pricing and availability!
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 40 V
- Current - Continuous Drain (Id) @ 25°C: 100A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 2.2mOhm @ 20A, 10V
- Vgs(th) (Max) @ Id: 2.2V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 165 nC @ 20 V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 8800 pF @ 25 V
- FET Feature: -
- Power Dissipation (Max): 107W (Tc)
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: TO-252AA
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
