TY-146P
Triad Magnetics
Triad Magnetics
TRANSF 600 AUDIO CT 150/600CT 15
$9.06
Available to order
Reference Price (USD)
1+
$8.39000
10+
$6.52100
25+
$6.34480
50+
$5.46360
100+
$5.21690
250+
$5.11112
500+
$5.02298
1,000+
$4.93486
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Achieve crystal-clear audio with Triad Magnetics TY-146P Audio Transformers, designed for versatility and top-notch performance. Perfect for use in studios, theaters, and home audio systems, these transformers ensure optimal signal transfer. Triad Magnetics is your trusted partner for high-end audio components. Reach out today for pricing and availability details.
Specifications
- Product Status: Active
- Turns Ratio - Primary:Secondary: 1:1
- Impedance - Primary (Ohms): 600, 150/150
- Impedance - Secondary (Ohms): 600, 150/150
- DC Resistance (DCR) - Primary: 17Ohm, 19Ohm
- DC Resistance (DCR) - Secondary: 14.5Ohm, 22Ohm
- Transformer Type: Data/Voice Coupling
- Frequency Range: 200Hz ~ 15kHz
- Frequency Response: ±2dB
- Voltage - Isolation: 1500V
- Insertion Loss: 1.5dB
- Return Loss: 26dB
- Power Level: 1W
- Operating Temperature: -20°C ~ 85°C
- Approval Agency: -
- Mounting Type: Through Hole
- Size / Dimension: 1.375" L x 1.187" W (34.93mm x 30.15mm)
- Height - Seated (Max): 1.187" (30.15mm)
- Termination Style: PC Pin
