CSD16570Q5BT
Texas Instruments
Texas Instruments
MOSFET N-CH 25V 100A 8VSON
$2.93
Available to order
Reference Price (USD)
250+
$1.65000
500+
$1.44376
750+
$1.30351
1,250+
$1.19625
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
CSD16570Q5BT by Texas Instruments is a standout in the Discrete Semiconductor Products market, specifically for Transistors - FETs, MOSFETs - Single applications. Engineered for precision, this MOSFET offers exceptional gate control, low leakage current, and high power density. Ideal for use in audio amplifiers, DC-DC converters, and battery management systems, CSD16570Q5BT ensures top-tier performance. Don t miss out on this versatile component request a sample or quote now!
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 25 V
- Current - Continuous Drain (Id) @ 25°C: 100A (Ta)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 0.59mOhm @ 50A, 10V
- Vgs(th) (Max) @ Id: 1.9V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 250 nC @ 10 V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 14000 pF @ 12 V
- FET Feature: -
- Power Dissipation (Max): 3.2W (Ta), 195W (Tc)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 8-VSONP (5x6)
- Package / Case: 8-PowerTDFN
