IXGA20N120A3-TRL
IXYS
IXYS
IXGA20N120A3 TRL
$4.22
Available to order
Reference Price (USD)
1+
$4.21565
500+
$4.1734935
1000+
$4.131337
1500+
$4.0891805
2000+
$4.047024
2500+
$4.0048675
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The IXGA20N120A3-TRL Single IGBT from IXYS redefines reliability in power electronics. Tailored for renewable energy, telecom, and defense applications, it offers ultra-low switching losses and high-frequency operation. With anti-parallel diodes and short-circuit ratings, it s built for safety and performance. IXYS stands behind every IXGA20N120A3-TRL with unmatched customer service. Start your order process by contacting our sales team today!
Specifications
- Product Status: Active
- IGBT Type: PT
- Voltage - Collector Emitter Breakdown (Max): 1200 V
- Current - Collector (Ic) (Max): 40 A
- Current - Collector Pulsed (Icm): 120 A
- Vce(on) (Max) @ Vge, Ic: 2.5V @ 15V, 20A
- Power - Max: 180 W
- Switching Energy: 2.85mJ (on), 6.47mJ (off)
- Input Type: Standard
- Gate Charge: 50 nC
- Td (on/off) @ 25°C: 16ns/290ns
- Test Condition: 960V, 20A, 10Ohm, 15V
- Reverse Recovery Time (trr): 44 ns
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package: TO-263 (D2Pak)
