NCD57090BDWR2G
onsemi
onsemi
ISOLATED HIGH CURRENT GATE DRIVE
$3.25
Available to order
Reference Price (USD)
1+
$3.25000
500+
$3.2175
1000+
$3.185
1500+
$3.1525
2000+
$3.12
2500+
$3.0875
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Boost your system s efficiency with onsemi NCD57090BDWR2G Gate Driver Isolators, built for rugged industrial environments. Highlights include high-speed data transfer, thermal shutdown protection, and robust construction. Ideal for servo drives, renewable energy converters, and medical devices, these isolators deliver consistent performance. Let s discuss your needs reach out today!
Specifications
- Product Status: Active
- Technology: Capacitive Coupling
- Number of Channels: 1
- Voltage - Isolation: 5000Vrms
- Common Mode Transient Immunity (Min): 100kV/µs
- Propagation Delay tpLH / tpHL (Max): 90ns, 90ns
- Pulse Width Distortion (Max): -
- Rise / Fall Time (Typ): 13ns, 13ns
- Current - Output High, Low: 6.5A, 6.5A
- Current - Peak Output: 6.5A
- Voltage - Forward (Vf) (Typ): -
- Current - DC Forward (If) (Max): -
- Voltage - Output Supply: 0V ~ 32V
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 8-SOIC
- Approval Agency: VDE
