NVMFS5C420NLT1G
onsemi
onsemi
POWER MOSFET, SINGLE, N-CHANNEL,
$3.42
Available to order
Reference Price (USD)
1+
$3.42000
500+
$3.3858
1000+
$3.3516
1500+
$3.3174
2000+
$3.2832
2500+
$3.249
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
For cutting-edge Transistors - FETs, MOSFETs - Single solutions, choose NVMFS5C420NLT1G by onsemi. A key player in Discrete Semiconductor Products, this MOSFET boasts low RDS(on), high current capacity, and excellent switching characteristics. Its applications span across telecom infrastructure, medical devices, and consumer electronics. Elevate your designs with NVMFS5C420NLT1G inquire now for more details!
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 40 V
- Current - Continuous Drain (Id) @ 25°C: 45A (Ta), 277A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 1mOhm @ 50A, 10V
- Vgs(th) (Max) @ Id: 2.2V @ 200µA
- Gate Charge (Qg) (Max) @ Vgs: 100 nC @ 10 V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 7020 pF @ 20 V
- FET Feature: -
- Power Dissipation (Max): 3.8W (Ta), 146W (Tc)
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 5-DFN (5x6) (8-SOFL)
- Package / Case: 8-PowerTDFN, 5 Leads
