PMZB950UPELYL
Nexperia USA Inc.
Nexperia USA Inc.
MOSFET P-CH 20V 500MA DFN1006B-3
$0.41
Available to order
Reference Price (USD)
10,000+
$0.11070
30,000+
$0.10278
50,000+
$0.09948
100,000+
$0.09900
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover PMZB950UPELYL, a versatile Transistors - FETs, MOSFETs - Single solution from Nexperia USA Inc., a trusted name in Discrete Semiconductor Products. This MOSFET combines high power density with low on-resistance, perfect for compact and energy-efficient designs. Applications include solar inverters, electric vehicles, and wearable technology. Interested in this innovative component? Send us your inquiry now for more information!
Specifications
- Product Status: Active
- FET Type: P-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 20 V
- Current - Continuous Drain (Id) @ 25°C: 500mA (Ta)
- Drive Voltage (Max Rds On, Min Rds On): 1.2V, 4.5V
- Rds On (Max) @ Id, Vgs: 1.4Ohm @ 500mA, 4.5V
- Vgs(th) (Max) @ Id: 950mV @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 2.1 nC @ 4.5 V
- Vgs (Max): ±8V
- Input Capacitance (Ciss) (Max) @ Vds: 43 pF @ 10 V
- FET Feature: -
- Power Dissipation (Max): 360mW (Ta)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: DFN1006B-3
- Package / Case: 3-XFDFN
