TY-303P
Triad Magnetics
Triad Magnetics
TRANSF 4000 OHM PRI. 0MA DC TEL
$5.88
Available to order
Reference Price (USD)
1+
$5.43000
10+
$4.12600
25+
$4.01720
50+
$3.69160
100+
$3.47440
250+
$3.36584
500+
$3.25726
1,000+
$3.14868
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover high-quality Triad Magnetics TY-303P Audio Transformers, designed to deliver exceptional sound clarity and performance. These transformers are perfect for audio applications, ensuring signal integrity and noise reduction. Whether you're working on professional audio equipment or consumer electronics, our Audio Transformers provide reliable performance. Contact us today for a quote and elevate your audio projects with Triad Magnetics excellence.
Specifications
- Product Status: Active
- Turns Ratio - Primary:Secondary: 2.43:1
- Impedance - Primary (Ohms): 4k
- Impedance - Secondary (Ohms): 600
- DC Resistance (DCR) - Primary: 260Ohm
- DC Resistance (DCR) - Secondary: 52Ohm
- Transformer Type: Data/Voice Coupling
- Frequency Range: 300Hz ~ 3.5kHz
- Frequency Response: ±0.5dB
- Voltage - Isolation: 1500VAC
- Insertion Loss: 1dB Typ
- Return Loss: 26dB Typ
- Power Level: -45dB ~ 7dB
- Operating Temperature: -20°C ~ 85°C
- Approval Agency: -
- Mounting Type: Through Hole
- Size / Dimension: 0.812" L x 0.715" W (20.62mm x 18.16mm)
- Height - Seated (Max): 0.740" (18.80mm)
- Termination Style: PC Pin
