CSD17559Q5
Texas Instruments
Texas Instruments
MOSFET N-CH 30V 40A/100A 8VSON
$3.09
Available to order
Reference Price (USD)
2,500+
$1.19700
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Boost your electronic applications with CSD17559Q5, a reliable Transistors - FETs, MOSFETs - Single by Texas Instruments. As a leader in Discrete Semiconductor Products, we offer components with low gate charge, high breakdown voltage, and excellent switching performance. Whether for aerospace, robotics, or energy systems, CSD17559Q5 meets the highest standards. Contact our team today for expert advice and competitive pricing!
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 30 V
- Current - Continuous Drain (Id) @ 25°C: 40A (Ta), 100A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 1.15mOhm @ 40A, 10V
- Vgs(th) (Max) @ Id: 1.7V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 51 nC @ 4.5 V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 9200 pF @ 15 V
- FET Feature: -
- Power Dissipation (Max): 3.2W (Ta), 96W (Tc)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 8-VSON-CLIP (5x6)
- Package / Case: 8-PowerTDFN
